ASROCK EPC602D8A - Page 10

4
English
Internal Connector
COM Port
Header
1 (COM2)
Auxiliary Panel
Header
1 (includes chassis intrusion, location button & LED, front
LAN LED)
TPM Header 1
ermal Sensor
Header
1
IPMB Header 1
Buzzer 1
Fan Header 5 x 4-pin
ATX Power 1 (24-pin) + 1 (8-pin)
USB 3.0 Header 1 (each supports 2 USB 3.0 ports)
USB 2.0 Header 1 (each supports 2 USB 2.0 ports)
Type A USB 2.0
Port
1
Front Audio
panel
1
SPDIF Header 1
1394 Header 1
Front Panel 1
Speaker 1
Dr. Debug with
LED
1
System BIOS
BIOS Type 64Mb AMI UEFI Legal BIOS
BIOS Features - Plug and Play (PnP)
- ACPI 1.1 Compliance Wake Up Events
- SMBIOS 2.3.1 Support
- DRAM Voltage Multi-adjustment
- ASRock Instant Flash
Hardware Monitor
Temperature - CPU Temperature Sensing
- System Temperature Sensing
Fan - CPU/Rear/Front Fan Tachometer
- CPU Quiet Fan (Allow CPU Fan Speed Auto-Adjust by CPU
Temperature)
- CPU/Rear/Front Fan Multi-Speed Control
Voltage Voltage Monitoring: CPU1/2, DRAM1/2, VCCM, VCCSA1/2,
3V/5V/ 12V, +1.05V_PCH, +BAT, 3VSB, 5VSB
