ASROCK EPC602D8A - Memory Coniguration; Memory Mode

EPC602D8A / EPC602D8A-V+
49
English
PCIE 1 & PCIE 2 Link Width
is allows you to select PCIE 1 & PCIE 2 Link Width. e default value is [Gen2].
PCIE 1 & PCIE 2 Link Speed
is allows you to select PCIE1 & PCIE2 Link Speed. e default value is [Auto].
PCIE 3 & PCIE 4 Link Width
is allows you to select PCIE 3 & PCIE 4 Link Width. e default value is [Gen2].
PCIE 3 & PCIE 4 Link Speed
is allows you to select PCIE3 & PCIE4 Link Speed. e default value is [Auto].
PCIE 5 & PCIE 6 Link Width
is allows you to select PCIE 5 & PCIE 6 Link Width. e default value is [Gen2].
PCIE 5 & PCIE 6 Link Speed
is allows you to select PCIE5 & PCIE6 Link Speed. e default value is [Auto].
Memory Conguration
Memory Mode
Select the mode for memory initialization.
•
[Independent]: Independent channel mode.
•
[Mirroring]: e memory subsystem writes identical data to two channels
simultaneously. Identical memory modules should be installed in the two channels
closest to the processor.
•
[Lock Step]: e two channels closest to the processor are combined to form a single
channel. Memory modules must be identical in size, speed, and technology in
corresponding slots.
•
[Sparing]: is mode occurs when on-demand inactive memory is automatically
activated by the system to temporarily replace failed memory until a service action can
be performed.
ECC Support
Use this item to enable or disable DDR ECC support.
DRAM RAPL BWLIMIT
is item sets the limits on the average power consumption and the bandwidth of a DRAM
module.
