ASROCK EPC602D8A - Page 15

EPC602D8A / EPC602D8A-V+
9
English
No. Description
1 Rear Fan Connector (REAR_FAN1)
2 USB 3.0 Header (USB3_3_4)
3 2 x 240-pin DDR3 DIMM Slots (DDR3_C2, DDR3_D2, White)
4 2 x 240-pin DDR3 DIMM Slots (DDR3_C1, DDR3_D1, Blue)
5 PSU SMBus (PSU_SMB1)
6 ATX 12V Power Connector (ATX12V1)
7 Front Fan Connector (FRONT_FAN1)
8 ATX Power Connector (ATXPWR1)
9 2 x 240-pin DDR3 DIMM Slots (DDR3_A2, DDR3_B2, White)
10 CPU Fan Connector (CPU_FAN1)
11 2 x 240-pin DDR3 DIMM Slots (DDR3_A1, DDR3_B1, Blue)
12 Front Fan Connector (FRONT_FAN2)
13 Auxiliary Panel Header (AUX_PANEL1)
14 SATA SGPIO Connector (SATA_SGPIO1)
15 SATA SGPIO Connector (SATA_SGPIO2)
16 SATA2 Connector (SATA_4), Blue
17 SATA3 Connector (SATA_M0), White
18 SATA3 Connector (SATA_M1), White
19 SATA2 Connector (SATA_5), Blue
20 Non Maskable Interrupt Button (NMI_BTN1)
21 Front Fan Connector (FRONT_FAN3)
22 SATA2 Connector (SATA_2), Blue
23 SATA2 Connector (SATA_3), Blue
24 SATA3 Connector (SATA_1), White
25 SATA3 Connector (SATA_0), White
26 SCU Connector (SCU_0-3)
27 TPM Header (TPM1)
28 USB 2.0 Header (USB_3_4)
29 ermal Sensor header (TR1)
30 System Panel Header (PANEL1)
31 Speaker Header (SPEAKER1)
32 BMC SMBus Header (BMC_SMB_3)
33 BMC SMBus Header (BMC_SMB_2)
