ASROCK Fatal1ty FM2A88X+ Killer Series User Manual

English
4
Audio
 7.1 CH HD Audio with Content Protection (Realtek
ALC1150 Audio Codec)
 Premium Blu-ray Audio support
 Supports Purity Sound
TM

- TI
®

to 600 ohm headsets)
- Direct Drive Technology
- EMI Shielding Cover
- PCB Isolate Shielding
 Supports DTS Connect
LAN
 PCIE x1 Gigabit LAN 10/100/1000 Mb/s
 Qualcomm
®
Atheros
®
Killer
TM
E2200 Series
 Supports Wake-On-LAN
 
 Supports PXE
Rear
Panel I/O
 1 x PS/2 Mouse/Keyboard Port
 1 x D-Sub Port
 
 1 x HDMI Port
 1 x Optical SPDIF Out Port
 3 x USB 2.0 Ports
 1 x Fatal1ty Mouse Port (USB 2.0)
 2 x USB 3.0 Ports (AMD A88X (Bolton-D4))
 2 x USB 3.0 Ports (ASMedia ASM1042A)
 1 x RJ-45 LAN Port with LED (ACT/LINK LED and
SPEED LED)
 1 x Clear CMOS Switch with LED
 HD Audio Jacks: Rear Speaker / Central / Bass / Line in
/ Front Speaker / Microphone

ASROCK Fatal1ty FM2A88X+ Killer Series Specifications

General

Socket	FM2+
Chipset	AMD A88X
Memory Support	DDR3
Max Memory	64GB
PCI Express 3.0 x16	1
PCI Express 2.0 x16	1
PCI Express 2.0 x1	2
PCI Slots	2
SATA 6Gb/s	8
Audio Chipset	Realtek ALC1150
Audio Channels	7.1
LAN Chipset	Qualcomm Atheros Killer E2200
Max. LAN Speed	10/100/1000Mbps
PS/2	1
Form Factor	ATX
Memory Slots	4
SATA RAID	0, 1, 5, 10
USB 3.0 Ports	4
USB 2.0 Ports	8
Audio Ports	1 x Optical S/PDIF
Video Ports	D-Sub, DVI-D, HDMI
Dimensions	305 x 244 mm
Power Pin	24-pin ATX
