Page #27 background image
English
20
2.4 Expansion Slots (PCI and PCI Express Slots)
There are 3 PCI slots and 4 PCI Express slots on this motherboard.
PCI Slots: PCI slots are used to install expansion cards that have the 32-bit PCI
interface.
PCIE Slots:
PCIE1 / PCIE3 (PCIe 2.0 x1 slot) is used for PCI Express cards with x1
lane width cards.
PCIE2 (PCIe 3.0 x16 slot) is used for PCI Express x16 lane width graph-
ics cards.
PCIE4 (PCIe 2.0 x16 slot) is used for PCI Express x4 lane width graph-
ics cards.

For a better thermal environment, please connect a chassis fan to the moth-
erboard’s chassis fan connector (CHA_FAN1, CHA_FAN2 or CHA_FAN3)
when using multiple graphics cards.
Before installing an expansion card, please make sure that the power supply
is switched off or the power cord is unplugged. Please read the documenta-
tion of the expansion card and make necessary hardware settings for the card
before you start the installation.
PCIE2 PCIE4
Single Graphics Card x16 N/A
Two Graphics Cards in
CrossFireX
TM
Mode
x16 x4

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the ASROCK Fatal1ty FM2A88X+ Killer Series and is the answer not in the manual?

ASROCK Fatal1ty FM2A88X+ Killer Series Specifications

General IconGeneral
SocketFM2+
ChipsetAMD A88X
Memory SupportDDR3
Max Memory64GB
PCI Express 3.0 x161
PCI Express 2.0 x161
PCI Express 2.0 x12
PCI Slots2
SATA 6Gb/s8
Audio ChipsetRealtek ALC1150
Audio Channels7.1
LAN ChipsetQualcomm Atheros Killer E2200
Max. LAN Speed10/100/1000Mbps
PS/21
Form FactorATX
Memory Slots4
SATA RAID0, 1, 5, 10
USB 3.0 Ports4
USB 2.0 Ports8
Audio Ports1 x Optical S/PDIF
Video PortsD-Sub, DVI-D, HDMI
Dimensions305 x 244 mm
Power Pin24-pin ATX
