2.3 Installation of Memory Modules (DIMM)
This motherboard provides four 240-pin DDR3 (Double Data Rate 3) DIMM
slots, and supports Dual Channel Memory Technology.

-
age to the motherboard and the DIMM if you force the DIMM into the slot at
incorrect orientation.
Priority DDR3_ A1 DDR3_A2 DDR3_B1 DDR3_B2
1 Populated Populated
2 Populated Populated
3 Populated Populated Populated Populated
1.

same brand, speed, size and chip-type) DDR3 DIMM pairs.
2.
It is unable to activate Dual Channel Memory Technology with only one or
three memory module installed.
3.
It is not allowed to install a DDR or DDR2 memory module into a DDR3
slot; otherwise, this motherboard and DIMM may be damaged.
4.
If you adopt DDR3 2600/2400/2133/1866/1600 memory modules on this
motherboard, it is recommended to install them on DDR3_A2 and DDR3_
B2 slots.
