ASROCK Fatal1ty FM2A88X+ Killer Series User Manual

English
12
No. Description
1 
2 Power Fan Connector (PWR_FAN1)
3 CPU Fan Connector (CPU_FAN1)
4 CPU Fan Connector (CPU_FAN2)
5 2 x 240-pin DDR3 DIMM Slots (DDR3_A1, DDR3_B1)
6 2 x 240-pin DDR3 DIMM Slots (DDR3_A2, DDR3_B2)
7 ATX Power Connector (ATXPWR1)
8 USB 3.0 Header (USB3_5_6)
9 Chassis Fan Connector (CHA_FAN3)
10 SATA3 Connectors (SATA3_1_ 2)
11 SATA3 Connectors (SATA3_3_4)
12 SATA3 Connectors (SATA3_5_6)
13 SATA3 Connectors (SATA3_7_8)
14 System Panel Header (PANEL1)
15 Chassis Fan Connector (CHA_FAN2)
16 Chassis Speaker Header (SPEAKER1)
17 Chassis Fan Connector (CHA_FAN1)
18 Power LED Header (PLED1)
19 Chassis Intrusion Header (CI1)
20 USB 2.0 Header (USB_9_10)
21 USB 2.0 Header (USB_7_8)
22 USB 2.0 Header (USB_5_6)
23
TPM Header (TPMS1)
24 SLI/XFIRE Power Connector (SLI/XFIRE_PWR1)
25 COM Port Header (COM1)
26 Front Panel Audio Header (HD_AUDIO1)
27 Clear CMOS Jumper (CLRCMOS1)

ASROCK Fatal1ty FM2A88X+ Killer Series Specifications

General

Socket	FM2+
Chipset	AMD A88X
Memory Support	DDR3
Max Memory	64GB
PCI Express 3.0 x16	1
PCI Express 2.0 x16	1
PCI Express 2.0 x1	2
PCI Slots	2
SATA 6Gb/s	8
Audio Chipset	Realtek ALC1150
Audio Channels	7.1
LAN Chipset	Qualcomm Atheros Killer E2200
Max. LAN Speed	10/100/1000Mbps
PS/2	1
Form Factor	ATX
Memory Slots	4
SATA RAID	0, 1, 5, 10
USB 3.0 Ports	4
USB 2.0 Ports	8
Audio Ports	1 x Optical S/PDIF
Video Ports	D-Sub, DVI-D, HDMI
Dimensions	305 x 244 mm
Power Pin	24-pin ATX
