ASROCK G41M-VS2 User Manual

2929
2929
29
DRAM CH0 RCOMP ODT
This controls the number of DRAM CH0 RCOMP ODT. Min: 1. Max: 63. The
default value is [Auto].
DRAM CH1 RCOMP ODT
This controls the number of DRAM CH1 RCOMP ODT. Min: 1. Max: 63. The
default value is [Auto].
DRAM CH0 tRD
This controls the number of DRAM CH0 TRD. Min: 0. Max: 30. The default
value is [Auto].
DRAM CH1 tRD
This controls the number of DRAM CH1 TRD. Min: 0. Max: 30. The default
value is [Auto].
DRAM CH0 tRD Phase Adjust
This controls the number of DRAM CH0 TRD Phase Adjust. Min: 0. Max: 62.
The default value is [Auto].
DRAM CH1 tRD Phase Adjust
This controls the number of DRAM CH1 TRD Phase Adjust. Min: 0. Max: 62.
The default value is [Auto].

ASROCK G41M-VS2 Specifications

General

Non-ECC	Yes
Number of memory slots	2
Maximum internal memory	8 GB
Processor socket	LGA 775 (Socket T)
Processor manufacturer	Intel
Compatible processor series	Intel® Celeron®
Number of Parallel ATA connectors	1
USB 2.0 ports quantity	4
Firewire (IEEE 1394) ports	0
Audio chip	Realtek ALC662
Certification	FCC, CE
Power source type	ATX
Audio output channels	5.1 channels
Motherboard form factor	micro ATX
Compatible operating systems	Win XP, Vista, 7
Maximum graphics card memory	1759 MB
Networking features	10/100 Mbps
BIOS memory size	64 Mbit

Weight and Dimensions

Depth	170 mm
Width	244 mm
