BIOS SETUP UTILITY
DRAM RCOMP STRENGTH Settings
Select Screen
Select Item
+- Change Option
F1 General Help
F9 Load Defaults
F10 Save and Exit
ESC Exit
v02.54 (C) Copyright 1985-2005, American Megatrends, Inc.
OC Tweaker
Select Screen
Select Item
+- Change Option
F1 General Help
F9 Load Defaults
F10 Save and Exit
ESC Exit
DRAM CH0 G0 (Data)
Value
Min=1
Max=15
DRAM CH0 G0 (Data)
[Auto]
DRAM CH0 G1 (Command)
DRAM CH0 G2 (Control1)
DRAM CH0 G3 (Control2)
DRAM CH0 G4 (Clocks1)
DRAM CH0 G5 (Clocks2)
[Auto]
[Auto]
[Auto]
[Auto]
[Auto]
DRAM CH0 RCOMP STRENGTH Info : 0-10-7-7-7-7
DRAM CH1 G0 (Data)
DRAM CH1 G1 (Command)
DRAM CH1 G2 (Control1)
DRAM CH1 G3 (Control2)
DRAM CH1 G4 (Clocks1)
DRAM CH1 G5 (Clocks2)
[Auto]
[Auto]
[Auto]
[Auto]
[Auto]
[Auto]
DRAM CH1 RCOMP STRENGTH Info : 0-10-7-0-7-0
DRAM RCOMP STRENGTH Configuration
DRAM CH0 G0 (Data)
This controls the number of DRAM CH0 G0 (Data). Min: 1. Max: 15. The
default value is [Auto].
DRAM CH0 G1 (Command)
This controls the number of DRAM CH0 G1 (Command). Min: 1. Max: 15. The
default value is [Auto].
DRAM CH0 G2 (Control1)
This controls the number of DRAM CH0 G2 (Control1). Min: 1. Max: 15. The
default value is [Auto].
DRAM CH0 G3 (Control2)
This controls the number of DRAM CH0 G3 (Control2). Min: 1. Max: 15. The
default value is [Auto].
DRAM CH0 G4 (Clocks1)
This controls the number of DRAM CH0 G4 (Clocks1). Min: 1. Max: 15. The
default value is [Auto].
DRAM CH0 G5 (Clocks2)
This controls the number of DRAM CH0 G5 (Clocks2). Min: 1. Max: 15. The
default value is [Auto].
DRAM CH1 G0 (Data)
This controls the number of DRAM CH1 G0 (Data). Min: 1. Max: 15. The
default value is [Auto].
DRAM CH1 G1 (Command)
This controls the number of DRAM CH1 G1 (Command). Min: 1. Max: 15. The
default value is [Auto].
DRAM CH1 G2 (Control1)
This controls the number of DRAM CH1 G2 (Control1). Min: 1. Max: 15. The
default value is [Auto].

ASROCK G41M-VS2 Specifications

General

Non-ECC	Yes
Number of memory slots	2
Maximum internal memory	8 GB
Processor socket	LGA 775 (Socket T)
Processor manufacturer	Intel
Compatible processor series	Intel® Celeron®
Number of Parallel ATA connectors	1
USB 2.0 ports quantity	4
Firewire (IEEE 1394) ports	0
Audio chip	Realtek ALC662
Certification	FCC, CE
Power source type	ATX
Audio output channels	5.1 channels
Motherboard form factor	micro ATX
Compatible operating systems	Win XP, Vista, 7
Maximum graphics card memory	1759 MB
Networking features	10/100 Mbps
BIOS memory size	64 Mbit

Weight and Dimensions

Depth	170 mm
Width	244 mm
