ASROCK PRO BTC+ Series User Manual

X370 Pro BTC+
3
English
AMD Ryzen series CPUs (Summit Ridge, Raven Ridge and
Pinnacle Ridge)
•
8 x PCI Express x16 Slots (PCIE1 at x4; PCIE2~8 at x1)
•
6 x Mining Ports (M_Port1~M_Port6 at x1)*
* Support USB Type Riser kit
Graphics
•
Integrated AMD Radeon
TM
Vega Series Graphics in Ryzen
Series APU*
•
Integrated AMD Radeon
TM
R-Series Graphics in A-series
APU*
* Actual support may vary by CPU
•
DirectX 12, Pixel Shader 5.0
•
Max. shared memory 4GB
•
Dual graphics output: Support HDMI and D-Sub ports by
independent display controllers
LAN
•
PCIE x1 Gigabit LAN 10/100/1000 Mb/s
•
Realtek RTL8111EPV
•
Supports Wake-On-LAN
•
Supports LAN Cable Detection
•
Supports Lightning/ESD Protection (ASRock Full Spike
Protection)
•
Supports Energy Ecient Ethernet 802.3az
•
Supports PXE
•
Supports DASH
Rear Panel
I/O
•
1 x PS/2 Mouse/Keyboard Port
•
1 x D-Sub Port
•
1 x HDMI Port
•
2 x USB 2.0 Ports (Supports ESD Protection)
•
2 x USB 3.1 Gen1 Ports (Supports ESD Protection)
•
1 x RJ-45 LAN Port with LED (ACT/LINK LED and SPEED
LED)
Storage
•
1 x SATA3 6.0 Gb/s Connector, supports NCQ, AHCI and
Hot Plug
•
1 x M.2 Socket, supports M Key type 2230/2242/2260/2280
M.2 SATA3 6.0 Gb/s module

ASROCK PRO BTC+ Series Specifications

General

Form Factor	ATX
CPU Socket	LGA 1151
Maximum Memory	32GB
Memory Slots	4
Storage Interface	6 x SATA3
USB Ports	6 x USB 2.0
LAN	1 x Gigabit LAN
Audio	7.1 CH HD Audio
M.2	1 x M.2
