ASROCK PRO BTC+ Series User Manual

English
4
Connector
•
1 x System Panel Header
•
1 x COM Port Header
•
1 x Power LED and Speaker Header
•
1 x CPU Fan Connector (4-pin)
* e CPU Fan Connector supports the CPU fan of maximum
1A (12W) fan power.
•
8 x Chassis Fan Connectors (4-pin)
* CHA_FAN1~2 support the chassis fan of maximum 1A (12W)
fan power. CHA_FAN3~8 support the chassis fan of maximum
2.5A (30W) fan power.
* CPU_FAN1, CHA_FAN1 and CHA_FAN2 can adjust 4-pin fan
speed.
•
3 x 24 pin ATX Power Connectors
•
1 x 8 pin 12V Power Connector
•
1 x 4 pin 12V Power Connector
•
6 x 4 pin PCIe Power Connectors
•
1 x USB 2.0 Header (Supports 2 USB 2.0 ports) (Supports ESD
Protection)
•
1 x Power Button
•
1 x Reset Button
BIOS
Feature
•
AMI UEFI Legal BIOS with multilingual GUI support
•
Supports “Plug and Play”
•
ACPI 5.1 compliance wake up events
•
Supports jumperfree
•
SMBIOS 2.3 support
•
DRAM Voltage multi-adjustment
Hardware
Monitor
•
CPU/Chassis temperature sensing
•
CPU/Chassis Fan Tachometer
•
CPU/Chassis Quiet Fan
•
CPU/Chassis Fan multi-speed control
•
Voltage monitoring: +12V, +5V, +3.3V, Vcore
OS
•
Microso® Windows® 10 64-bit
•
Linux: Ubuntu 16.04 LTS / Fedora 25

ASROCK PRO BTC+ Series Specifications

General

Form Factor	ATX
CPU Socket	LGA 1151
Maximum Memory	32GB
Memory Slots	4
Storage Interface	6 x SATA3
USB Ports	6 x USB 2.0
LAN	1 x Gigabit LAN
Audio	7.1 CH HD Audio
M.2	1 x M.2
