Concealed Vertical Rod Exit Device
7220
Installation Instructions
11
80-9472-0020-000 10/23
1-800-438-1951 • www.assaabloy.com
Copyright © 1999, 2013, 2023, ASSA ABLOY Access and Egress Hardware Group, Inc. All rights reserved. Reproduction in whole
or in part without the express written permission of ASSA ABLOY Access and Egress Hardware Group, Inc. is prohibited.
For use in conjunction with instruction sheets packed with exit device.
Holes and slots are identifi ed below by exit device series and trim. Prep door and frame for only those features required for the
exit device being installed.
Door
Template
Door Stop
Frame
All 7000 Exit Devices
Vertical Reference
Wide Stile
Trim Only
Against Door Stop
or Mullion
(when applicable)
7120(F), 7160(F)
& 7220M(F) CVR
Vertical Reference
All 7000 Exit Devices
757F
Strike
Location
Narrow Stile
Trim Only
Against Door
Surface
Wide Stile
Trim Only
Horizontal
Reference
Wide Stile
Trim Only
7120(F), 7160(F)
& 7220M(F) CVR
To Next Page
