Assa Abloy 813C-50 User Manual

ASSA ABLOY motor locks installation guide
9
Lock types: ASSA motor lock 813C, 815C, 820C,
825C, 835C
Technical data
Indications on start-up Supply voltage Current (A) Power (W)
Operating (standby) 12.0 / +20 degrees 0.081 0.97
Operating (standby) 24.0 / +20 degrees 0.044 1.06
Switching on/off handle 12.0 / +20 degrees 0.22 2.64
Switching on/off handle 24.0 / +20 degrees 0.095 2.28
Locking hook bolt 12.0 / +20 degrees 0.58 6.96
Locking hook bolt 24.0 / +20 degrees 0.33 7.9
Power consumption
EA226
Cable Length 10m
Maximum length 50m
Cable length, cable area
at 12 V
20 m 0.3 mm
2
30 m 0.4 mm
2
40 m 0.5 mm
2
50 m 0.6 mm
2
Lock case Lock case, drill protection (835C-50). Manual accessible using QR code.
Complete set
Lock case, drill protection, I/O Box 350, cable EA226, striking plate c/w contact magnet, wood screws,
cable transition EA281.
ARX set Lock case, connecting cable EA226 and striking plate c/w contact magnet.
PoE Lock case 835C should not be used with PoE & local control unit 9101.
Accessories
813C-50
815C-50
825C-50
820C-50
825C-50
835C-50
Cylinder type Round, oval
Striking plate 1487-1, -2, -3, -4, -5 (c/w contact magnet)
Cable EA226
Cable transition EA281
Thumb turn 256 thumb turn, double round oval cylinder, solenoid thumb turn.
Cylinder accessories
Opening hardware
Handle Std. /
Stiffening accessory
256 or 3212 depending on configuration
8065 for round thumb turn cylinder or 179 handle
–
4292
Package contents
