6 Models
Two main models of the PowerSwing are available:
• Single Operator
• Double Operator
The operators are non-handed and not dependent on the hinges. The operators can be
used on both pushing and pulling arm systems.
6.1 Single Operator
The product is delivered complete with back plate, control unit, end plates and cover.
Length including end plates, L = 51" or 88".
Pushing arm system shown.
6.2 Double Operator (Consult Product Order form for availability)
The product is delivered complete with back plate, control unit, end plates and cover.
Cover length L is optional.
Two operators can be mounted under the same cover to open one door each.
Pushing and pulling arm system shown (double egress).
L
ILL-00448
L
ILL 00449
