Assa Abloy Besam PowerSwing CSDB - Signage and Decals; Application of Door Safety Signage

40 Issue 2008-11-13 1004935-US-1.0
14 Signage
* To meet ANSI A156.10 Power Operated Pedestrian door standard for one-way and
two-way traffic applications.
50± 12"
50± 12"
34-48"
50± 12"
58±5"
C
L
Apply to both sides of the door.
When using a wall switch,
apply to both sides of the door.
Apply the push decal to the push
side and the pull decal to the pull
side of the door.
Push plate
PRES
S
TO
OPEN
*
