1004935-US-1.0 Issue 2008-11-13 23
9.4 Fastening requirements
* Besam minimum recommended requirements. Building Codes may give different
specifications. Refer to AHJ (Authority Having Jurisdiction).
** Thinner wall profiles must be reinforced with rivnuts.
9.5 Tools required
• Torx T8, T10, T20 and T25
• Metric hexagonal key 3, 4 and 6 mm
• Flatblade screwdriver, small
• Torque wrench with metric Allen socket 6 mm
• Carpenter’s level
• Tape rule
• Power drill and set of drill bits
• Center punch
• Wire stripper
• Silicone sealant
• Installation and Service Manual 1004935-US-1.0 (this manual)
9.6 Installation on double doors
If the operators are to be mounted at the same height with pushing and pulling arm
systems, the height is determined by the pulling arm system, PULL. The pushing arm
system PUSH/SAS-F must always have a shaft extension, minimum 2".
Example: If PULL has a 3/4" extension, the PUSH/SAS-F must have a 2 3/4" exten-
sion.
For installation follow the instructions for the applicable arm system.
Base material Minimum requirements of wall profile*
Steel 3/16" **
Aluminum 1/4" **
Reinforced concrete min. 2" from the underside
Wood 2"
Brick wall Expansion-shell bolt, min. M6x85, UPAT PSEA
B10/25, min. 2" from the underside
