EN
Mounting
1 Frame profile 6 Spacer plate
2 Cover 7 Cover
3 Escape door locking
system 352M
8 Mounting bracket
4 Mounting bracket 9 One-rivet nut
5 Lock counterpart 10 Door leaf profile
1234567
8
1
1
max. 4,5 mm
min. 2 mm
1 2 3
4
5
6
7
8
10 9
Fig. 5:
Mounting on the
door frame with
screw-on casing
