Mounting
A
Attention!
Restricted movement if the gap to the vertical frame section is incorrect: If
the gap to the vertical frame section is too small, the door can no longer move
freely and can no longer be fully opened.
207
150,
5
6,4
180
10
23
18
10
max. 46,5
min. 42
Fig. 6:
Drilling jig for
mounting
