A7113E • 800-810-WIRE (9473) • www.sargentlock.com
Keypad 10 Line Lock
8/14/08 Copyright © 2005, 2007,2008, Sargent Manufacturing Company, an ASSA ABLOY Group company. All rights reserved.
Reproduction in whole or in part without the express written permission of Sargent Manufacturing Company is prohibited.
General Description
The SARGENT Keypad 10 Line Lock is designed for areas which require authorized entry. It is a
self-contained microprocessor-controlled keypad with non volatile solid-state memory. The keypad will
hold a total of 100 different User Codes. User Codes “01” and “03” are utilized for Master Code and
Supervisory Code, respectively. All programming is done at the keypad, with over 1,100,000 possible
user combinations.
This lock is operated by four (4) “C” batteries with a life span of approximately 50,000 cycles.
A portable infrared printer (52-2069) may be used to download user information.
• Latch bolt - 1/2" standard
3/4" available (41-prefix)
• Deadlocking latch
• Outside lever controlled by keypad or key retracts latch bolt
• Inside lever retracts latch
• Locks furnished for 1-3/4" doors only
• U.L. Listed
Specifications
