2
800-810-WIRE (9473) • www.sargentlock.com • A7113E
12/15/07 © SARGENT Manufacturing Company 2005, 2007. All rights reserved.
Keypad 10 Line Lock
8/14/08 Copyright © 2005, 2007,2008, SARGENT Manufacturing, an ASSA ABLOY Group company. All rights reserved.
Reproduction in whole or in part without the express written permission of SARGENT Manufacturing is prohibited.
Parts Breakdown
ITEM PART NUMBER DESCRIPTION NO. REQ’D
1
*10-0523 “B” Inside lever/regular and 30- 1
*
10-2204 “J” Inside lever/regular and 30- 1
*
10-0503 “L” Inside lever/regular and 30- 1
*10-0547 “P” Inside lever/regular and 30- 1
*10-0536 “B” Inside lever/75 handicap warning 1
*
10-2247 “J” Inside lever/75 handicap warning 1
*
10-0514 “L” Inside lever /75 handicap warning 1
*
10-0558 “P” Inside lever/75 handicap warning 1
S
ee SARGENT web page for Costal Series Levers.
2 *10-0790 Rose scalp "G" 2
2A *10-0798 Rose scalp "L" 2
4
10-0792 Spacer bushing 2
5
10-3048 Inside rose spring assembly (not finished) 1
6 01-9170 Through-bolt screws 2
6A 10-0802 Plastic screw holder 2
7 01-4388 8 X 1 SELF TAP SCREW 1
7
A 82-0443 Turn lever cover plate, plastic -black. not shown 1
9
*10-2875 Inside escutcheon assembly 1
9A 52-2400 Controller/circuit board assembly only 1
10 45-1340 Flat head screw (security) 1
1
0A 52-0069 Battery cover only 1
1
1 01-0297 SOCKET ALLEN SAFETY KEY 1
1
2 *52-2340 Outside escutcheon & keypad 1
12A 52-2299 Keypad assembly only 1
13 01-1500 SELF TAP SCREW TYPE "AB" 2
14 52-0033 Fire stop plate and screws 1
15 10-2642 77 Lockbody (std, 10, 21, 23, 30, SC, SE, VA & VS prefixes only) 1
15A 10-2643 77 Lockbody (60, 63, 64 prefixes only) 1
15B 10-2644 77 Lockbody (70, 72, 65-73, 65-73P lockbody) 1
16 10-3049 Outside rose spring assembly (not finished) 1
17 10-0019 Cylinder spacer 1
17A 13-3613 Schlage (SC) cylinder (provide keying details) 1
17B 13-3614 Schlage (SE) cylinder (provide keying details) 1
17C 13-3713 Cylinder (10-Signature) 1
18 10-0312 Cylinder retainer 1
18A 10-0313 Cylinder retainer for removable core, 1
Interchangeable core & Keso
19 13-3266 Cylinder (standard) provide keying details 1
20 *10-2251 “B” Lever outside standard cylinder 1
*10-2205 “J” Lever outside standard cylinder 1
*10-0502 “L” Lever outside standard cylinder 1
*10-0546 “P” Lever outside standard cylinder 1
*10-0525 “B” Outside lever/30-competitive cylinder 1
*10-2206 “J” Outside lever/30-competitive cylinder 1
*10-0503 “L” Outside lever/30-competitive cylinder 1
*10-0547 “P” Outside lever/30-competitive cylinder 1
*10-0535 “B” Outside lever/standard cylinder 76 handicap warning 1
*10-2246 “J” Outside lever/standard cylinder 76 handicap warning 1
*10-0513 “L” Outside lever/standard cylinder 76 handicap warning 1
*10-0557 “P” Outside lever/standard cylinder 76 handicap warning 1
See SARGENT web page for Costal Series Levers.
21 Key (provided with cylinder) A/R
22 *10-2000 2-3/4" Backset latch (standard) 1
22A 10-2053 3-3/4" Backset latch (23 prefix) 1
22B *10-2058 5" Backset latch (25 prefix) 1
22C *10-2634 3/4" Throw (41 prefix) 1
23 01-4414 Screw for standard front and strike 4
24 *08-0312 #800 Strike 1
24A *08-0066 #808 Strike (28-prefix) 1
25 *10-2052 Screw pack- standard (screws (latch, strike, #3) & push pin tool) 1
*
10-2070 Screw pack- 28- prefix (screws (front, strike, #3) &push pin tool)
1
26 52-2300 Screw pack (includes #’s 7, 11, 13, 14, 28, 28A, 29) 1
27 08-0055 Strike Box- standard 1
28 01-1157 8-32unc-2ax 1 1/4 1
28A 01-9063 WASHER 1
29 01-1119 PH FL HD 8-32 X 1 1/2 1
30 10-0043 Lever Retainer Push Pin, Not Shown 1
3
*Specify Finish
