4
800-810-WIRE (9473) • www.sargentlock.com • A7113E
12/15/07 © SARGENT Manufacturing Company 2005, 2007. All rights reserved.
Keypad 10 Line Lock
8/14/08 Copyright © 2005, 2007,2008, SARGENT Manufacturing, an ASSA ABLOY Group company. All rights reserved.
Reproduction in whole or in part without the express written permission of SARGENT Manufacturing is prohibited.
Features
KP10G77
• Non volatile memory
• Motor driven, battery operated cylindrical lock
• Battery operated with 4 each “C” Alkaline Batteries
• Low battery alert–4 chirps after code entry
• Option Code available to sound horn every time keypad is pressed
• External remote “request to exit” connector
• External battery input connector included to power unit in event of battery failure
• 100 users total: one Master Code, one Supervisory Code, with the rest being standard codes,
passage codes, or one time only codes
• All programming done at keypad
• Operates utilizing any two to six digits per code. Digits may be repeated and codes may start
with zero
• Minimum 40,000 cycles per set of batteries
• Cylinder override provided
• Entry of three wrong User Codes disables all codes for ten seconds. Green LED flashes
• Piezo horn can be heard with each keystroke or turned off by Master or Supervisory Code
• Last 15 transactions can be output to portable printer via infrared link
Keypad
• Made of ultraviolet stable material
• LED’s indicate valid or invalid entries
• Green LED indicates unlocked. Yellow LED indicates unit is in programming mode
• Flashing green and yellow LED’s indicate lock in passage mode
• Infrared LED for transaction output. Indicates last 15 valid codes
Items included in your KP10G77 Keypad Cylindrical Lock:
• Outside Escutcheon with Keypad
• Motorized Cylindrical Lock with cylinder
• Inside escutcheon with circuit board and battery pack
• Batteries (4 “C”)
• Tools
