4 1-800-810-WIRE • www.sargentlock.com • A8011H
Copyright © 2016, Sargent Manufacturing Company, an ASSA ABLOY Group company. All rights reserved.
Reproductions in whole or in part without express written permission of Sargent Manufacturing Company is prohibited.
04/30/16
Passport 1000 P2 Mortise Lock
General Description
2
Hardware Specifications
3
Electronic Specifications
4
• Complete lockset with controller
• ADA compliant
• Easily retrofits existing Passport 1000 door
preps (mortise)
• Latch - Stainless steel
• Optional deadbolt - Stainless steel
• Guardbolt - Stainless steel, non handed
• Handing (RH/RHR/LH/LHR) must be
specified, but is easily field-reversible with-
out opening the lock case
• Case - 12 gauge heavy duty wrought steel
• Cylinder retracts latchbolt (and deadbolt)
• Inside lever retracts latch and deadbolt simultaneously
• ANSI/BHMA A156.25 Listed Grade 1 Compliant
• May be used for indoor and outdoor applications
• Lock furnished for 1-3/4” doors.
For other thicknesses, consult factory.
• Outside lever controlled by any combination
of keypad, magnetic swipe, contactless
reader, or mechanical cylinder
• WiFi (IEEE 802.11 b/g/n)
• Multiple time zone and holiday access scheduling
• First-in unlock or automatic unlock configuration,
based on specified time schedule
• Support for most advanced wireless encryption
and authentication standards such as WEP, WPA,
WPA2 and 802.1x*
• 2,400 users per lock; 10,000 event audit trail
• Privacy button
*For specific security information, please contact your local
ASSA ABLOY Door Security Solutions sales consultant or call
800-810-WIRE.
• HID
®
multiCLASS SE
®
technology offers
support for the following credentials:
• 2.4 GHz credential compatibility:
• 125 kHz credential compatibilty:
• HID Prox
®
• Secure Identity Object™ (SIO) on
Mobile IDs (Bluetooth Smart)
• 13.56 MHz credential compatibility:
• iCLASS
®
• iCLASS SE
®
(SIO-enabled)
• iCLASS Seos
®
• SIO on MIFARE
®
Classic
• SIO on MIFARE
®
DESfire
®
EV1
• MIFARE
®
Classic
• DESfire
®
EV1
• NFC-enabled mobile phones
Destructive Attack Level 1
Line Security Level 1
Endurance Level 4
Standby Power Level 1
• UL Listed - UL 294 Indoor Use
• CUL Listed - S319: Class 1
• UL 294 Access Control Ratings:
Power Requirements:
• Alkaline AA Batteries: 9VDC, 300mA
• Optional Hard Power (UL294 Listed Power
Supply Required): 9-24VDC, 300mA
An ANSI/BHMA Grade 1 lock using WiFi technology, the Passport 1000 P2 Mortise lock provides a
cost-effective, future-proof solution for campuses.
Featuring multiCLASS SE
®
Technology from HID Global
®
, it provides simultaneous support for multiple
credentials and offers an easy migration path to higher security credentials and mobile access.
With no wiring required, installation is fast, easy and affordable.
Note: A weather-protective gasket is required for outdoor applications.
