Deleting All Card Users
9.Unlocking
Unlocking with a Fingerprint
Essential Series Essential Series
Example
Operation
Unlocking with a Card
Unlocking with a Code
Turn the Handle
Turn the Handle
Unlocking with a Key
Keep pressing the switch
on back side of the handle.
Push the handle
panel to the right.
10 11
Input “Master Code”
Input “Master Code”
Turn the Handle
Press”#”
Press”#” Press”#”
Press”6#” Press”6#”
Press”#”
Input “3-Digit User ID”(Twice)”
Input “12345678”
Input “12345678”
Input “001”
Input a valid 8-digit code
Swipe a valid card
Front Lock Body
Reset
11.Reset
10.Change Batteries(8 ) x1.5V AA Alkaline Batteries
Turn the battery cover switch to “Unlock Status”
Turn the battery cover switch to “Lock Status”
Replace all old batteries with new batter
Remove the battery Cover
Install battery Cover
Connect the power wire on the front lock body with the batteries.
Keep pressing the RESET button on the rear metal plate of the front
lock body with a small stick for several seconds and touch the screen
to wake up the lock. Operation succeeds after hearing a long beep.
Lock will return to factory default status with master code 11111111
and all its memory is cleared.
“ ”
YDME - 90 YDME - 90
