Assa Abloy Yale YRD216-ZW3 Integrator Guide

27
11
One Touch
Locking
1 byte
0x00
(Disable)
0xFF
(Enable)
0xFF
(Enable)
Set One Touch Locking
feature to enable or disable.
51
12
Privacy
Button
1 byte
0x00
(Disable)
0xFF
(Enable)
0x00
(Disable)
Set Privacy Button feature to
enable or disable.
48
13
Lock Status
LED
1 byte
0x00
(Disable)
0xFF
(Enable)
0x00
(Disable)
Set Lock Status LED feature
to enable or disable.
49
16
Escape
Return
Mode**
1 byte
0x00
(Disable)
0xFF
(Enable)
0x00
(Disable)
Enable or Disable Escape
Return Mode
36
21
Eco Mode
On/Off**
1 byte
0x00
(Disable)
0xFF
(Enable)
0x00
(Disable)
Enable or Disable Eco Mode
feature
34
28
Expiring Pin
Code
Enabled
Time
1 byte
0x00
(Disable)
0xFF (127
Hours)
0x00
(Disable)
Timeout value used to
determine time after first
entry is triggered.
68
*Only supported by YRC/D226/256/652/622/642 & NF-YRC/D622
** Only supported by YRC/D622/642
