9
P/N - - - Rev BYRL EMICL PBINSTL FUL
Lockset Handing Configurations
4" Left Hand
For 5.5"
For 4"
4" Right Hand
For 5.5"
For 4"
After handing is changed, check that lever and thumbturn rotate freely.
Test Lever and Thumbturn
