:: :: Turnbuckles Build - Step 2
:: :: Turnbuckles Build - Step 1Turnbuckles Build - Step 1
:: :: Rear Hub and CVA Build - Step 2Rear Hub and CVA Build - Step 2
91722
Ball Cup
91722
Ball Cup
91723
Turnbuckles,
3x48mm
Build x2 (right and left side)
Orient the notch
to the left throughout the
car. It indicates which end
has the left hand threads!
!
91436
CVA Wheel
Hex Pin
91418
Wheel
Hex (rear)
Build x2 (right and left side)
Racers Tip:
Use black grease
(#6588) on the
threads of the
turnbuckles for
easier ball cup
installation!
28.00mm
Steering Turnbuckle
Build x2 (right and left side)
Racers Tip:
Use black grease
(#6588) on the
threads of the
turnbuckles for
easier ball cup
installation!
Front Camber Turnbuckle
23.00mm
91722
Ball Cup
91722
Ball Cup
91723
Turnbuckles,
3x48mm
31510
M2 x 4mm
BHCS
91394
Hinge Pin
(rear, outer)
Orient the notch
to the left throughout the
!
Racers Tip:
Use black grease
3x48mm
Use black grease
Orient the notch
to the left throughout the
car. It indicates which end
has the left hand threads!
!
