Associated Electrics SR10 - Front Top Plate and Steering Build; Front Top Plate and Steering Build - Step 1; Front Top Plate and Steering Build - Step 2; Front Top Plate and Steering Build - Step 3

8
:: :: Front Top Plate and Steering Build - StepFront Top Plate and Steering Build - Step 2 2
:: :: Front Top Plate and Steering Build - Step 3Front Top Plate and Steering Build - Step 3
:: Front Top Plate and Steering Build - Step 1:: Front Top Plate and Steering Build - Step 1
Do not overtighten steering bolts. Make sure
there is free movement in the steering rack.
!
Note orientation
of steering rack.
!
Note orientation
of the brace.
!
91475
3 x 7 x 3
Ball Bearing
91391
Steering
Rack
x4x4
x2x2
x2x2
91047
Heavy-duty
Ballstud,
6mm
91391
Steering
Rack Crush
Tube
91391
Steering
Bellcrank
Brace
x2x2
89202
M3 x 12mm
BHCS
91047
Heavy-duty
Ballstud,
6mm
91391
Steering
Bellcrank
Brace
91475
3 x 7 x 3
Ball Bearing
x4x4
x2x2
25189
M3 x 22mm
BHCS
91358
Chassis
Brace Set
(Top Plate)
x2x2
25202
M3 x 10mm
FHCS
91359
Bulkhead
71092
Chassis
