Associated Research Hypot II 4500D User Manual

QUICK START
25
5. If the instrument defaults are acceptable then be sure to connect the appropriate test leads
to the device under test (DUT) or test fixture. Be sure to connect this safety ground to a
suitable known good ground before energizing this instrument, connect the return lead first
(black) to the test fixture or item followed by the high voltage output lead (red).
6. Please check your connections to be sure they are making good contact.
Clear the area of any debris that may create a hazardous situation and ask
any unnecessary personnel to leave the area. DO NOT TOUCH THE
DEVICE UNDER TEST ONCE THE TEST HAS BEEN STARTED. To initiate the test
press the GREEN test button on the front panel. This is a momentary button and does not
need to be held in the pressed position during the test. The instrument will then cycle ON
and begin the automated test sequence using the defaults. If a failure occurs you will HEAR
an audible alarm go off. To stop the alarm you must depress the RED button marked
RESET. This will silence the alarm and reset the instrument to begin another test. This
RESET button may also be used as a safety button to quickly ABORT a test and cut off the
HIGH VOLTAGE.
When HIGH VOLTAGE is present a RED flashing indicator located above
the HV receptacle will remain flashing until the HIGH VOLTAGE is OFF.
If the DUT PASSED the test, you will hear a brief BEEP indicating the
DUT passed and that the test is complete.
In the case of a FAIL condition, the instrument will provide a memory of the
test condition results on the LCD display that will remain until the next test is initiated.
Depressing the reset button will reset the instrument alarm while keeping the last test results
on the display. Depressing the reset button a second time will clear the display.
WARNING
