SPECIFICATIONS
13
Model 4500D
Functional Specifications
Unless otherwise stated, accuracy’s are relative to a laboratory standard measurement.
DIELECTRIC WITHSTAND TEST MODE
Descriptions Specifications
INPUT VOLTAGE
115 / 230V selectable, ± 10 % variation
50/60 Hz ± 5%
FUSE 115 VAC, 230VAC – 15A fast acting 250VAC
OUTPUT Rating AC 0 – 5000V, 10V / step, 100mA
Regulation : ± (1 % of output + 5V)
VOLTAGE SETTING 0V – Max output rating, 10 volts/step
Accuracy: ± (2 % of Setting + 5V) (relative to displayed output)
Can be adjusted during operation via UP and DOWN arrow
keys.
OUTPUT
FREQUENCY
50 / 60 Hz selectable
WAVE FORM Sinewave, 1.3 < Crest Factor < 1.5
DWELL TIME
SETTING
0 and 0.2 – 999.9 seconds, 0.1 second / step
“0” for continuous running
RAMP TIME
SETTING
0 and 0.2 – 999.9 seconds, 0.1 second / step
0 ramp setting = 0.1 seconds fixed ramp
FAILURE SETTINGS AC mode
High limit : 0.00 – 99.99 mA, 0.01 mA / step
Low limit : 0.00 – 99.99 mA, 0.01 mA / step (0= OFF)
Accuracy : ± (2 % of setting + 0.02 mA)
Voltmeter (4 digits)
Range : AC 0.00 – 5.00 KV
Resolution : 0.01 KV
Accuracy : ± (2 % of reading + 10 V)
Ammeter (4 digits)
Range : AC 0.00 - 99.99 mA
Resolution : 0.01 mA
METERING
Accuracy : ± (2 % of reading + 0.02 mA)
TIMER DISPLAY Range : 0.0 – 999.9 seconds
Resolution : 0.1 seconds
Accuracy : ± (0.1% of reading + 0.05 sec)
