PARTS LIST
42
Replacement Parts List HYPOT II
Model 4500D
ECO 5172 REV D
Part Number Qty. Reference
Designator
Description
38111 1 CHV-4500 High Voltage Control Board
37593 1 CKB-02 Key Board Assembly
38135 1 CSW-05 Input Protection Board
38110 1 4500 Main Control Board
38112 1 AMP-510 Power Amplifier Board
38113 1 REC-19 Rectifier Board
37571 1 - Earth Connector
35999 4 - Black Banana Jacks
37478 2 - High Voltage Connector
38101 1 - Feet Kit w/o Rubber Inserts
38102 4 - Rubber Insert for Feet
38788 2 - 3U Rack Mount Bracket
38787 2 - 3U Rack Mount Handle
37999 1 - Fuse 15A, 250V, Fast Blow, 20 mm
37554 1 - LCD Display 16 x 2 Characters
38109 1 - Power Switch 2P 10A/250V
37673 1 - Test Switch, Green
37497 1 - Reset Switch, Red
38075 1 - Interlock Connector Std. M/F
38108 1 T-4500-T2 Output High Voltage Transformer
38107 1 T-4500-T1 Input Transformer
38071 1 - Input Power Cable 15A/6Ft.
04040A-08 1 - High Voltage Output cable
02100A-13 2 - Return cable
37697 1 U9 Microcontroller 8 Bit P89C52
38009 1 U10 IC W27E257 EEPROM
37605 2 FAIL,READY Bulbs
