CALIBRATION
41
Then press the SET key on the front panel. The instrument will provide around
5000VAC on the output connectors and the display will show:
Voltage= XXXX V
Please use the Up/Down Arrow keys to enter the reading off the AC Voltmeter,
into the instrument. Then press the SET key to store the voltage setting. Press
the EXIT or RESET key to return to the calibration menu without changing the
calibration setting.
The instrument will output two short “beeps” when attempting to save a missing
or bad parameter and will not allow return to the calibration menu.
1.2. Calibration of Dielectric Withstand Current
Equipment needed: STANDARD AC MILLIAMMETER with a range of 100mA
and a fixed Resistor 10K Ohms, 100 watts.
Please connect a 10KΩ resistor in series with the standard ac milliammeter and
connect these across the output leads of the instrument. Press the Down Arrow
key. The instrument will provide around 1000VAC on the output and the display
will show:
Current= X.XX mA
Please use the Up/Down Arrow keys to enter the reading of the standard AC
milliammeter, into the instrument. Then press the SET key to store the current
setting. Press the EXIT or RESET key to return to the calibration menu without
changing the calibration setting.
The instrument will output two short “beeps” when attempting to save a missing
or bad parameter and will not allow return to the calibration menu.
1.3. Save Calibration
After the calibration, the instrument has to be turned off to save the calibration
parameters. The power must be turned off and on again to switch from the
calibration mode to the run mode.
