OPERATION
27
2.2. To set the Output Test Voltage
Please press the SET key until the display shows:
Voltage= X.XX KV
Please use the Up/Down Arrow keys to enter the desired test voltage, then press
the EXIT key to exit to the test mode or toggle to another setting using the SET
key. The maximum voltage, which may be entered, is 5000 volts AC.
2.3. To set the High Leakage Current Limit
Please press the SET key until the display shows:
HI-LMT =XX.XX mA
Use the Up/Down Arrow keys to enter the leakage current high limit setting, then
press the EXIT key to exit to the test mode or toggle to another setting using the
SET key. The unit of measure is in AC milliamperes with 0.10 milliamperes as the
minimum setting.
2.4. To set the Low Leakage Current Limit
Please press the SET key until the display shows:
LO-LMT = X.XX mA
Use the Up/Down Arrow keys to enter the leakage current low limit setting, then
press the EXIT key to exit to the test mode or toggle to another setting using the
SET key. The unit of measure is in AC milliamperes with 0.00 milliamperes as the
minimum setting.
2.5. To set the Ramp Time
Please press the SET key until the display shows:
Ramp-T = X.X s
Use the Up/Down Arrow keys to enter the ramp time setting then press the EXIT
key to exit to the test mode or toggle to another setting using the SET key. If the
ramp time is set to “0”, the instrument will raise the voltage up to the test voltage
in a fixed ramp time of 0.1 seconds and then begin the dwell cycle. The minimum
ramp time setting is 0.2 seconds with 0.1 second resolution.
