Associated Research SC6540-HH User Manual

9
1.5. Key Features of the SC6540
CONFIGURABLE
SCANNING MATRIX
The SC6540 can be purchased as a “main” scanning
matrix with its own power source, or as a “secondary”
scanning matrix controlled through an automated
Associated Research instrument. Each main Scanner can
control up-to four additional secondary Scanners,
allowing a total of 80 test points.
UP TO 16 HIGH
VOLTAGE
SWITCHING
OUTPUTS
High voltage outputs are rated for up to 5 kVAC and 6
kVDC to handle a wide range of safety agency
specifications.
UP TO 16 HIGH
CURRENT
SWITCHING
OUTPUTS
High current channels allow ground bond testing to be
incorporated into automated testing applications. Outputs
are rated for up to 40 Amps.
AUTOMATED
MULTI-POINT OR
MULTI-PRODUCT
TESTING
CAPABILITIES
When used in conjunction with OMNIA® or
HypotULTRA®, the SC6540 reduces test setup time and
eliminates operator error to ensure consistent test results.
AUTOMATION
INTERFACES FOR
SOFTWARE
CONTROL
Main Scanners are available with USB/RS-232, GPIB and
Ethernet automation interfaces.
FRONT PANEL
INDICATORS
LED’s indicate the status of each channel. The operator
can clearly see which output is active.
POINT TO POINT
CONTINUITY TESTS
High voltage channels can also be used for point-to-point
Continuity tests.
COMPACT 2U RACK
MOUNT DESIGN
This space saving design allows the SC6540 to be
quickly and easily installed into a rack mount system.

Associated Research SC6540-HH Specifications

General

Brand	Associated Research
Model	SC6540-HH
Category	Multiplexer
Language	English
