5.7.4. IEEE 488.2 Common Commands
These commands are required by the IEEE-488.2 standard with the exception of
*PSC, *PSC?. Most of these commands are not available over the RS-232 bus
except for the *IDN? command which can be used to retrieve the instrument
identification information, and the four status reporting commands *ESR?, *ESE,
*ESE? and *STB?
COMMAND
NAME
DESCRIPTION
*IDN?
Identification Query
Associated Research Inc., Model
Number, Serial Number,
Firmware Revision
*RST
Reset Command
Resets SC6540
*TST?
Self-Test Query
00H=OK
01H=TEST EEPROM ERROR
*CLS
Clear Status Command
Clear Standard Event Status
Register
Clear Service Request Register
*OPC
Operation Complete Command
When all selected pending
operations complete, ESR BIT0
= 1
*OPC?
Operation Complete Query
When all selected pending
operations complete, Output
Queue = 1
*WAI
Wait-to-Continue Command
*PSC {1|0}
Power-on Status Clear Command
1 = Power-on clear enable
registers
0 = Power-on load previous
enable registers
*PSC?
Power-on Status Clear Query
*ESR?
Standard Event Status Register
Query
0 - 255
*ESE <value>
Standard Event Status Enable
Command
value = 0 - 255
*ESE?
Standard Event Status Enable
Query
0 - 255
*STB?
Read Status Byte Query
Read Status Byte
*SRE
<value>
Service Request Enable Command
value = 0 - 255
*SRE?
Service Request Enable Query
0 - 255
*IDN?
Read the instrument identification string. Company = Associated Research Inc.
Note: serial number information is not stored in the instrument’s memory; a serial number of “0” will
be returned in the character string.
