*ESE?
Queries the Standard Event enable register. Returns the decimal value of the
binary-weighted sum of bits.
*STB?
Read the Status Byte. Returns the decimal value of the binary-weighted sum of
bits.
*SRE <value>
Service Request enable register controls which bits from the Status Byte should
be use to generate a service request when the bit value = 1.
*SRE?
Queries the Service Request enable register. Returns the decimal value of
binary-weighted sum of bits.
5.7.5. Ethernet Card Setting Commands and Companion Queries
These commands require Ethernet protocol.
COMMAND
NAME
VALUE
SIM {1|0}
SIM?
Set IP Mode
1=Manual, 0=Auto
(DHCP/BOOTP)
SIA <value>
SIA?
Set IP Address
Dotted decimal form. Ex.
192.168.1.50
SGA <value>
SGA?
Set Gateway IP
Address
Dotted decimal form
SSM <value>
SSM?
Set Subnet Mask
Dotted decimal form
SDN <value>
SDN?
Set Device Name
8 character max, must start with
a letter
MAC?
MAC Address Query
Example response:
00:20:4A:8B:B4:30
DIP?
DIP Switch Query
Binary Value of DIP Switch
Configuration
5.7.6. Status Reporting
Status reporting system is configured using two types of registers. An Event
Register and a Summary register. The summary register is known as the Status
Byte register and records high-level summary information acquired by the event
registers.
An Event register report defined conditions or messages at each bit. The bits are
latched and remain at an active state until the register is either Read or Cleared.
Reading the event register automatically clears the register and sets all bits to
