There are 5 different Scanner models available, each varying by Module number
and type. See the table below:
If a Scanner only has 8 ports (HN, GN), these ports will always be located
in Module A.
4.2. Operating the SC6540 with HypotULTRA / HypotULTRA III
NOTE: The HypotULTRA III series is discontinued and replaced by
HypotULTRA.
4.2.1. Cables and Connections Description
A number of hardware and interconnect cables are included with the SC6540
Scanner depending on its configuration and the number of modules. The following
hardware and interconnect cables are included with each of the following items:
SC6540 SECONDARY AND HYPOTULTRA /
HYPOTULTRA III INTERCONNECT CABLES
1 – 25-Pin Scanner Bus Cable
SC6540 MAIN AND HYPOTULTRA / HYPOTULTRA III
INTERCONNECT CABLES
SC6540 HIGH VOLTAGE MODULE
8 – High Voltage Connectors and Assembly Instructions
1 – 100 ft. (48.75 m) Reel of High Voltage Cable
The 25-pin scanner bus cable (p/n 38592) connects between the rear panel
SCANNER connector of HypotULTRA / HypotULTRA III and the rear panel
SCANNER BUS INPUT of the SC6540 secondary scanning matrix.
