PHOENIX Talon - Operation and Service Manual

NOTE:

If the Gas run is more than 25’, use the connection size on the burner shown in Table-2 below.

Table 2 - Feed Pipe Size, for Gas Runs Over 25 Feet

NOTE:

If the Gas run is 25 feet or less. use the connection size on the burner shown in Table-3 below.

Table 3 - Feed Pipe Size, for Gas Runs 25 Feet or Under

4. The supplied manual shutoff valve, must be installed upstream of the gas control regulator.

a. The strainer protects the valves from destructive dirt that could lodge in them.

b. This shutoff valve facilitates servicing of the gas control train.

c. The Siemens gas valves have an integral strainer at the inlet of the valve.

5. The gas company should purge the main gas line for scale and dirt before it is attached to the burner

gas manifold.

NOTE:

Install the flexible fitting supplied with the burner gas manifold to reduce flexing of the manifold produced

by plant vibrations.

Table 4 - Recommended Pipe Nipple

Burner Model PT-50 PT-75 PT-100 PT-125 PT-150

Pipe Size

(Minimum Dia.)

4" 6" 6" 6" 8"

FEED PIPE SIZE, FOR GAS RUNS OVER 25 FEET

Burner Model PT-50 PT-75 PT-100 PT-125 PT-150

Pipe Size

(Minimum Dia.)

4" 4" 4" 6" 6"

FEED PIPE SIZE, FOR GAS RUNS 25 FEET OR UNDER

Burner Model PT-50 PT-75 PT-100 PT-125 PT-150

ASTEC

Part Number

076046 048292 048292 048292 048292

ASTEC PART NUMBERS, FLEXIBLE PIPE NIPPLES
