2.2.6 Manual bypass
It‘s used to by-pass the UPS, supplying the load directly to the mains in case of
maintenance or serious failure.
WARNING
The sequence of bypass switching must be carried out with respect to the procedure
indicated on the UPS and in the chapter “Start-up, shut-down and manual bypass”. The
manufacturer cannot accept responsibility for damages arising from incorrect operation.
2.2.7 Front panel
The front panel of the UPS, consisting of a double row alphanumeric displays plus 5
function keys, allows the complete monitoring of the UPS status.
The mimic diagram helps to understand the operating status of the UPS.
For more information see the chapter “FRONT PANEL”.
