Front panel
4 OM226131 Rev. A
2. DESCRIPTION
2.1 MIMIC DESCRIPTION
Picture1 shows the mimic present on the display, with the names of the circuit
breakers/isolator switches of the UPS. Also the led's and blocks that comprise the UPS
are clearly identified.
LED 1 ⇒ Lit-up green = Mains present at the rectifier input.
Otherwise off.
LED 2 ⇒ Lit-up green = Emergency line present and phase
sequence correct.
Otherwise off.
LED 3 ⇒ Lit-up green = Rectifier feeding correctly.
Lit-up red = Rectifier output voltage out of tolerance.
LED 4 ⇒ Lit-up green = Battery OK.
Green flashing = Battery discharging or battery in test.
Orange flashing = BCB open.
Lit-up red = Battery test aborted.
LED 5 ⇒ Lit-up green = Inverter static switch closed.
Otherwise off.
LED 6 ⇒ Lit-up orange = Emergency line static switch closed.
Otherwise off.
LED 7 ⇒ Lit-up green = Voltage present on the load.
Lit-up orange = OCB circuit breaker open.
LED 8 ⇒ Lit-up orange = Manual by-pass closed. Otherwise off.
LED 9 ⇒ Lit-up red = EPO push-button pressed (Evolution mimic
only).
