Insert the Seat Post (43) into the seat tube located on the Main Frame (49).
Insert the Seat Slider (42) into the Seat Post (43), tighten the Seat Slider Adjustment
Knob (51) to secure the Seat Slider (42) in place.
Secure the Saddle (1) onto the post of the Seat Slider (42), tighten the saddle clamp
screw to secure the Saddle (1) in place.
Use Seat Adjustment Knob (6) to adjust height of the saddle, use Seat Slider
Adjustment Knob (51) to adjust the saddle back and forth.
Assembly Instruction
49
42
1
43
51
STEP: 3
