ASUS LCD TV Monitor T1 Series 22
3.2 Specifications Summary
1. 22T1E
Power Requirement
100 – 240V AC, 50 / 60 Hz
Power Consumption
Maximum: less than 70 W
Stand-by: less than 2 W
Power off: less than 1 W
Dimensions (W x H x D)
540.6 mm x 438.5 mm x 78.4 mm
Gross Weight
8.0 kg (with packing & accessories)
Net Weight
6.3 kg
Wall-Mount
Not applicable
Environmental
Conditions
Operating temperature between 0°C and 40°C
Operating humidity between 10% and 70%
Storage temperature between -20°C and 60°C
Storage humidity between 10% and 70%
Panel Type
Thin-Film-Transistor Liquid-Crystal Display (TFT-LCD)
Viewing Area
475mm (H) x 267mm (V)
54.6cm (21.5”) wide diagonal
Pixel Pitch
0.248mm (H) x 0.248mm (V)
Physical Resolution
1920 (H) x 1080 (V)
Luminance
Maximum 300 cd/m
2
Contrast Ratio
Maximum 20,000:1 (when ASCR on)
Number of Colours
16.7 million colours
Colour Gamut
72% NTSC
Synchronization
Frequency
Horizontal 30 – 82 kHz
Vertical 50 – 76 Hz
Max. Pixel Frequency
162 MHz
Signal Connectors
19-pin HDMI x 2, 15-pin D-Sub, RCA R+L audio-in,
3.5mm mini-jack audio-in, 3.5mm mini jack
headphone-out, SCART x 2, Component, Composite,
S-Video, RCA R+L audio-out, S/PDIF optical audio-out,
IEC 169-2 RF connector
Speakers
7W (RMS) x 2 (stereo)
TV System
Analogue B/G, D/K, L, I
Digital DVB-T
Colour System
PAL, SECAM
NTSC 3.58, 4.43 (video-in only)
Channel Coverage
Analogue 48.25 – 855.25 MHz
Digital VHF Band III (177.5 – 226.5 MHz)
UHF E21 – E69 (474 – 858 MHz)
* Specifications are subject to change without prior notice.
