ASUS H97I-PLUS
1-13
9. Optical S/PDIF Out port.Thisportconnectsanexternalaudiooutputdeviceviaan
opticalS/PDIFcable.
10. USB 3.0 ports 3 and 4.These9-pinUniversalSerialBus(USB)portsconnecttoUSB
3.0/2.0devices.
 DONOTconnectakeyboard/mousetoanyUSB3.0portwheninstallingWindows
®
operating system.
 DuetoUSB3.0controllerlimitation,USB3.0devicescanonlybeusedunder
Windows
®
OSenvironmentandaftertheUSB3.0driverinstallation.
 USB3.0devicescanonlybeusedasdatastorageonly.
 WestronglyrecommendthatyouconnectUSB3.0devicestoUSB3.0portsforfaster
andbetterperformanceforyourUSB3.0devices.
11. HDMI port.ThisportisforaHigh-DenitionMultimediaInterface(HDMI)connector,
andisHDCPcompliantallowingplaybackofHDDVD,Blu-ray,andotherprotected
content.
12. DVI-D port. ThisportisforanyDVI-Dcompatibledevice.DVI-Dcantbeconvertedto
outputRGBSignaltoCRTandisntcompatiblewithDVI-I.
 Multi-VGAoutputsupportsuptothreedisplaysunderWindows
®
OSenvironment,two
displaysunderBIOS,andonedisplayunderDOS.
 Intel
®
display architecture design supports the following maximum supported pixel
clocks(PixelClock=HtotalxVTotalxFrameRate(Screenrefreshrate)):
 - DVIportsupports:165MHz
 - DisplayPortsupports:533MHz
 - HDMIportsupports:300MHz
13. USB 3.0 ports 5 and 6.These9-pinUniversalSerialBus(USB)portsconnecttoUSB
3.0/2.0devices.
Audio 2.1, 4.1, 5.1, or 7.1-channel configuration
Port
Headset
2.1-channel
4.1-channel 5.1-channel 7.1-channel
LightBlue(Rear
panel)
LineIn RearSpeakerOut RearSpeakerOut RearSpeakerOut
Lime(Rearpanel) Line Out FrontSpeakerOut FrontSpeakerOut FrontSpeakerOut
Pink(Rearpanel) MicIn MicIn Bass/Center Bass/Center
Lime(Frontpanel) – – – SideSpeakerOut
To configure a 7.1-channel audio output:
 UseachassiswithHDaudiomoduleinthefrontpaneltosupporta7.1-channelaudio
output.
