H97I-PLUS specifications summary
Internal connectors
1 x 19-pin USB 3.0/2.0 connector supports additional 2 USB ports
1 x USB 2.0/1.1 connector supports additional 2 USB ports
1 x M.2 Socket 3
4 x SATA 6.0 Gb/s connectors (gray)
1 x 4-pin CPU Fan connector for 4-pin (PWM mode) CPU cooler control
2 x 4-pin Chassis Fan connectors for both 3-pin (DC mode) and 4-pin
(PWM mode) coolers control
1 x Front panel audio connector (AAFP)
1 x S/PDIF out header
1 x 24-pin EATX Power connector
1 x 8-pin EATX 12V Power connector
1 x System panel connector
1 x MemOK! button
1 x Speaker connector
1 x 2-pin Clear CMOS header
1 x TPM header
BIOS features
64 Mb Flash ROM, UEFI AMI BIOS, PnP, DMI 2.0, WfM 2.0, SM BIOS
2.8, ACPI 2.0a, Multi-language BIOS, ASUS EZ Flash 2, ASUS CrashFree
BIOS3,MyFavorites,QuickNote,LastModiedLog,F12PrintScreen
function, F3 Shortcut functions, and ASUS DRAM SPD (Serial Presence
Detect) memory information
Manageability
WfM 2.0, DMI 2.0, WOL by PME, PXE
Support DVD Drivers
ASUS utilities
EZ Update
Anti-virus software (OEM version)
OS support Windows
®
8.1
Windows
®
8
Windows
®
7
Form factor
Mini-ITX form factor: 6.7 in. x 6.7 in. (17.0 cm x 17.0 cm)
Specicationsaresubjecttochangewithoutnotice.
