2 Knowing the Parts
Front Side
Refer to the diagram below to identify the components on the front side of the Notebook PC.
Multimedia Power LED and Control Buttons
(described in section 3)
Display Panel Latch
One display panel latch is used to lock the display panel in the closed position.
Status Indicators
Status indicator details are described in section 3.
Display Panel LatchCD Power LED Status IndicatorsCD Control Buttons
