Asus M2V - Create Array; Raid 0 for Performance

ASUS M2V 5-13
Create Array
1. From the VIA RAID BIOS utility main menu, select Create Array then
press <Enter>. The main menu items on the upper-left corner of the
screen are replaced with create array menu options.
RAID 0 for performance
1. From the create array menu, select Array Mode, then press <Enter>.
The supported RAID congurations appear on a pop-up menu.
2. Select RAID 0 for performance then press <Enter>.
From this point, you may choose to auto-congure the RAID array
by selecting Auto Setup for Performance or manually congure the
RAID array for stripped sets. If you want to auto-congure, proceed to
the next step, otherwise, skip to step 5.
3. Select Auto Setup for Performance and press <Enter>. The
following conrmation message appears.
RAID 1 for data protection
RAID 0/1
RAID SPAN for capacity
RAID 0 for performance
Auto create array will destroy all
data on disks, Continue? (Y/N)
Auto Setup For Data Security
Array Mode RAID 1 (Mirroring)
Select Disk Drives
Start Create Process
VIA Tech. RAID BIOS Ver 1.xx
Create a RAID array with
the hard disks attached to
VIA RAID controller
F1 : View Array/Disk Status
↑ , ↓ : Move to next item
Enter : Conrm the selection
ESC : Exit
Channel Drive Name Array Name Mode Size(GB) Status
Serial_Ch0 Master XXXXXXXXXXX ARRAY 0 SATA 999.99 XXXXXXX
Serial_Ch1 Master XXXXXXXXXXX ARRAY 0 SATA 999.99 XXXXXXX
