Asus M2V - Motherboard Layout

ASUS M2V 2-3
2.2.3 Motherboard layout
Socket AM2
20.5cm (8.0in)
30.5cm (12.0in)
VIA
K8T890
VT8237A
DDR2 DIMM_B1 (128 bit,240-pin module) DDR2 DIMM_A1 (128 bit,240-pin module) DDR2 DIMM_B2(128 bit,240-pin module) DDR2 DIMM_A2 (128 bit,240-pin module)
PCIEX16_1
PCIEX1_1
PCI1
PCI2
PCI3
PCI4
EATXPWR
ATX12V
AAFP
COM1
CD
FLOPPY
USB56
PANEL
SB_PWR
USBPW2
CLRTC
CHASSIS
SATA2SATA1
CHA_FAN2
CHA_FAN1
SPDIF_OUT
SATA_RAID1
CR2032 3V
Lithium Cell
CMOS Power
USB78
SEC_IDE PRI_IDE
CPU_FAN
KBPWR
USBPW1
PS/2KBMS
T: Mouse
B: Keyboard
Below:Mic In
Center:Line Out
Top:Line In
RJ-45
Top:
USB3
USB4
Bottom:
USB12
PARALLEL PORT
ESATA_1
SPDIF_O1
ALC660
4Mb
BIOS
LAN
SUPER I/O
M2V
Marvell
88SE6121
