Asus M3A78-T User Manual

6-3
ASUS M3A78-T
Using the onboard graphics card
1. Right-click on the Windows
®
desktop, and then click ATI CATALYST(R)
Control Center from the shortcut menu. The ATI CATALYST Control Center
screen appears.
2. Click Graphics Settings >
CrossFire™, then clear the Enable
CrossFire™ check box. When a
confirmation message pops up,
click Yes. The screen blacks out for
about one minute.
3. Click OK.
If you are using both an add-on and the on-board graphics cards at same time
and want to set the onboard graphics card as your main monitor, follow the
instructions on the next page.
4. Right-click on the Windows
®
desktop, then click Personalize
from the shortcut menu.
5. Click Display Settings. Select
[Default Monitor] on ATI Radeon
HD 3200 Graphics, then select the
check boxes of This is my main
monitor and Extend the desktop
onto this monitor. Click OK, and
then Yes from the confirmation
window.
6. Restart the system. Right-click on
the Windows
®
desktop, then click
ATI CATALYST(R) Control Center
from the shortcut menu. The ATI CATALYST Control Center screen appears.
7. Click Graphics Settings > CrossFire™, then select the Enable
CrossFire™ check box. When a coonfirmation pops up, click Yes. The
screen blacks out for about one minute.
8. Click OK. The onboard graphics card is set to be the main monitor.
