Asus M3A78-T User Manual

ASUS M3A78-T
2-31
9. Front panel audio connector (10-1 pin AAFP)
This connector is for a chassis-mounted front panel audio I/O module that
supports either HD Audio or legacy AC`97 audio standard. Connect one end
of the front panel audio I/O module cable to this connector.
• We recommend that you connect a high-denition front panel audio
module to this connector to avail of the motherboard’s high-denition audio
capability.
• If you want to connect a high-denition front panel audio module to this
connector, set the Front Panel Support Type item in the BIOS setup to
[HD Audio]; if you want to connect an AC'97 front panel audio module to
this connector, set the item to [AC97]. By default, this connector is set to
[HD Audio].

Asus M3A78-T Specifications

General

Brand	Asus
Model	M3A78-T
Category	Motherboard
Language	English
