DISASSEMBLY PROCEDURE
M2*3L
7. Detach the right & left antenna and its cable.
8. Reomve the speaker cable, then remove 1screw(M2*3L(K)) and 1 screw on the other
side.Then take two speaker s away
TOP CASE
MODULE
M2*3L
s
p
eaker
9. Detach the LCD hooker and spring then take it away.
3 - 10
