1-2
Chapter 1: Product Introduction
1.3 Monitor introduction
1.3.1 Front View and Charging Instructions
1
3
4
5
2
Menu
Close
Volume
Input Select
Brightness
1. Power
button/Power LED
• Press this button to turn the monitor on/off when connected to a valid
source.
• The color definition of the power indicator is as the below table.
Status Description
Blue Power on mode
Dark OFF
Orange Standby mode
2. 5 way key
• Turns on the button functions menu.Enacts the selected OSD menu item.
• Increases/Decreases values or moves your selection up/down/left/right.
3. USB Type-C port
• This port connects the power adapter or USB Type-C compatible device.
4. Mini-HDMI port
• Connect your computer with Mini-HDMI cable.
5. Earphone jack Port:
• Used to connect Earphone jack.
To Next Page
